REMOVAL AND INSTALLATION


Post-installation Operation
  • Rear Gate Fit Adjustment (Refer to ).




Striker removal


1.
 Striker



Rear gate removal steps


·
 Wiring harness connector connection


2.
 Rear body rear gate link


3.
 Rear gate link hook


4.
 Rear gate assembly



Hinge removal steps


5.
 Shim (0 - several pieces)


6.
 Hinge



Damper removal


7.
 Damper
