Pre-removal operation
- Removal of headlamp support panel cover (Refer to GROUP 51 - Front Bumper Assembly and Radiator Grille
 ) <Only removal of horn(LOW)>
- Removal of front bumper and radiator grille assembly (Refer to GROUP 51 - Front Bumper Assembly and Radiator Grille ) <Only removal of horn(HIGH)>
|
Post-installation operation
- Installation of headlamp support panel cover (Refer to GROUP 51 - Front Bumper Assembly and Radiator Grille ) <Only removal of horn(LOW)>
- Installation of front bumper and radiator grille assembly (Refer to GROUP 51 - Front Bumper Assembly and Radiator Grille ) <Only removal of horn(HIGH)>
|
