Pre-removal Operation
- Engine Room Under Cover Front A, B and Engine Room Side Cover Removal (Refer to GROUP 51 - Under Cover
 ).
- Front Exhaust Pipe Removal (Refer to GROUP 15 - Exhaust Pipe and Main Muffler <BWC> ).
- Intercooler Air Pipe D and Intercooler Air Pipe Bracket Removal (Refer to GROUP 15 - Intercooler ).
|
Post-installation Operation
- Intercooler Air Pipe D and Intercooler Air Pipe Bracket Installation (Refer to GROUP 15 - Intercooler ).
- Front Exhaust Pipe Installation (Refer to GROUP 15 - Exhaust Pipe and Main Muffler <BWC> ).
- Engine Room Under Cover Front A, B and Engine Room Side Cover Installation (Refer to GROUP 51 - Under Cover ).
|
