Pre-removal operation
- Control link arm removal (Refer to
 .)
- Upper arm removal (Refer to .)
- Rear suspension stabilizer bar removal.
- Exhaust Centre Pipe and Exhaust Main Muffler Removal (Refer to GROUP 15 - Exhaust
Pipe and Main Muffler <4A9>, <4B1>).
- Exhaust Centre Pipe and Exhaust Main Muffler Removal (Refer to GROUP 15 - Exhaust
Pipe, Main Muffler and Catalytic Converter <2WD>, <4WD>). <4N1>
- Driveshaft removal (Refer to GROUP 27B - Driveshaft assembly .)
- Rear differential assembly removal (Refer to GROUP27B - Differential carrier
assembly <4WD>.)
|
Post-installation operation
- Rear differential assembly installation (Refer to GROUP27B - Differential
carrier assembly <4WD>.)
- Driveshaft installation (Refer to GROUP 27B - Driveshaft assembly .)
- Exhaust Centre Pipe and Exhaust Main Muffler Installation (Refer to GROUP 15 - Exhaust
Pipe and Main Muffler <4A9>, <4B1>).
- Exhaust Centre Pipe and Exhaust Main Muffler Installation (Refer to GROUP 15 - Exhaust
Pipe, Main Muffler and Catalytic Converter <2WD>, <4WD>). <4N1>
- Rear suspension stabilizer bar installation.
- Upper arm installation (Refer to .)
- Control link installation (Refer to .)
- Rear wheel alignment check and adjustment.
- Check the beam direction of the headlamp (Low beam) (Refer to GROUP 54A - Headlamp
Aiming ).
|
